NASA’s Ames Research Center Wind Tunnels

Swept-wing model mounted in the 6 x 6 supersonic wind tunnel  1948
photograph
Collection of NASA
A-1743
R2022.2201.001

An arrow-wing model in the 6 x 6 supersonic wind tunnel  1958
photograph
Collection of NASA
A-24035
R2022.2201.004

Supersonic transport configuration model in 40 x 80 wind tunnel  1964
photograph
Collection of NASA
A-33012
R2022.2201.006

North American XP-51B Mustang airplane with outer wing structures
removed in 16 ft wind tunnel  1943
photograph
Collection of NASA
ARC-1943-AAL-3782
R2022.2201.012

NACA Ames computers reading the manometer (pressure measurements) board
for the 16 ft wind tunnel and calculating the test data  1943
photograph
Collection of NASA
ARC-1943-AAL-4962
R2022.2201.013

Supersonic 6 x 6 wind tunnel compressor showing rotor blades  1949
photograph
Collection of NASA
ARC-1949-A-14376
R2022.2201.016
